3MM Natural Stone Coated Aluminum Coils for Ceiling / Roofing And ACP / AHP

Brand Name : WILLSTRONG

Model Number : AA1100, AA3003

Certification : CE/ TUV/ ISO9001

Place of Origin : China

MOQ : 20 Tons

Price : USD 2300~4000

Payment Terms : L/C, T/T

Supply Ability : 30 tons/day

Packaging Details : In Pallets

Delivery Time : 5 working days

Color : WILLSTRONG color chart or RAL / PANTON

Coating Type : Roller Coating

Width : 1020mm, 1240, 1250mm, 1520, 1590mm

Coil weight : 2tons /3tons

Inner diameter : 150mm, 405mm, 505mm

Outer diameter : around 1200mm

Coating : PVDF / PET

Flexibility : ≤2

Contact Now

Stone Color PVDF/Feve/Pet Color Coated Aluminum Coils for Ceiling/Roofing and ACP/Ahp Production

3MM Natural Stone Coated Aluminum Coils for Ceiling/Roofing and ACP/AHP

WILLSTRONG color-coated aluminium coil combines all advantages of modern coil-coating technology in our full-automatic production line. we can created pattern like Wood, stone, graphic as you want. The aluminium substrate gets degreased, chemically pre-treated and coated in a single production step which resulting in a high-quality uniform coating reproducible at any time and a material which has been developed for easy processing for a variety of application.

WHAT COATING MATERIAL CAN BE?

Coating type

Ployester

PVDF

FEVE

WHAT IS THE SPCIFICATION OF WILLSTRONG COLOR COATED ALUMINUM COIL?

Aluminum Alloy

Aluminum

1100, 3003, 5005

Temper

H18. H16, H14

Other alloy and temper is available upon requirements

Size
Thickness	0.08~1.0mm
Width	1020mm,1240mm,1250mm, 1520mm, 1590mm, 1620mm
Coil Weight	2tons, 3tons
Inner Diameter	150mm, 405mm, 505mm
Outside Diameter	Around 1200mm

3MM Natural Stone Coated Aluminum Coils for Ceiling / Roofing And ACP / AHP

WHAT IS THE STRONGPOINT OF WILLSTRONG COLOR COATED ALUMINUM COIL?

Color Coated Aluminum Coil Characteristics	High temperature resistant
	Weathering resistant
	Scrubbing resistant
	Acid or alkali proof
	Sound insulation
	Fireproof
	Light weight material is easy to construct and install
	Bright colors
	Easy molding process,not rusting etc

APPLICATION OF WILLSTRONG COLOR COATED ALUMINUM COIL?

Application	1.Widely used in insulation board
	2.Aluminum curtain wall
	3.Aluminum-magnesium-manganese roofing system
	4.Aluminum ceiling
	5.Acp and many other areas

3MM Natural Stone Coated Aluminum Coils for Ceiling / Roofing And ACP / AHP

Product Tolerance

Thickness

0.2~0.3mm

0.3~0.5mm

0.5~1.0mm

Tolerance

±0.015mm

±0.020mm

±0.025mm

Width Tolerance

±1.5mm

For bespoke sizes and tolerance, plese contact us

Mechanical Properties
Alloy	Temper	Thickness/MM	δb/Mpa	δ0.2/Mpa	Elongation δ(500mm)/%
1100	H18	0.2~0.3	≥155	/	≥1
		>0.3~0.5			≥2
		>0.5~1.0			≥3
3003	H14 H24	0.2~0.3	140~180	>120	≥1
		>0.3~0.5			≥2
		>0.5~1.0			≥3
	H16 H26	0.2~0.3	165~205	≥145	≥1
		>0.3~0.5			≥2
		>0.5~1.0			≥3
5005	H18	0.2~0.8	175	/	≥1
		>0.8~1.3		≥125	≥2
		>1.3~1.6		≥125	≥3
	H14 H24	0.2~0.8	155~195	/	≥1
		>0.8~1.3		≥110	≥2
		>1.3~1.6		≥110	≥3
	H16 H26	0.2~0.8	120~155	/	≥3
		>0.8~1.3		≥85	≥4
		>1.3~1.6		≥85	≥6

3MM Natural Stone Coated Aluminum Coils for Ceiling / Roofing And ACP / AHP
